規格型號

Model

連接管內徑d0(mm)
Inner diameter for Connecting pipe

連接螺紋尺寸Size of connecting thread

長度L

length

備注

Remarks

英制G(BS)

公制M(MS)

NGe13×700

13

G1/2"

M20×1.5
M22×1.5

700

(1)撓性管長度可根據現場使用需要定制

The length of the dust-proof flexible hose would be determined according to the site requirements.

(2)螺紋規格可按現場需要定制成公制螺紋或NPT螺紋

The thread specification would be metric or NPT thread according to the site requirements.

NGe20×700

20

G3/4"

M24×1.5
M27×1.5

700

NGe25×700

25

G1"

M32×1.5

700

NGe32×1000

32

G1 1/4"

M40×1.5

1000

NGe38×1000

38

G1 1/2"

M50×1.5

1000

NGe51×1200

51

G2"

M60×1.5

1200

NGe64×1200

64

G2 1/2"

M75×1.5

1200

NGe75×1400

75

G3"

M90×1.5

1400

NGe100×2000

100

G4"

M110×2.0

2000
